SWIT FM-21HDR 21.5-inch film production monitor compatible with major cameras

The SWIT FM-21HDR is 21.5” IPS LCD panel with 1920×1080 resolution, 1000nit high brightness and H/V 178 ° view angle, is suitable for film production, studio and broadcast applications. The monitor features HDR HLG/BT.2100 & SMPTE ST 2084/Dolby vision PQ.

It also provides a wide range of professional features such as: waveform, vector scope, histogram, peaking/focus assist, false colour, Anamorphic Desqueeze, built-in multi cameras De-log LUTs and DIT LUTs upload by USB. The monitor has an audio metre which can display up to 16-channel SDI embedded audio or two-channel HDMI audio levels and with a choice of options including level reference settings and gain. FM-21HDR monitor is compatible with standard VESA mounting hardware.

The FM-21HDR provides more than 20 De-log 3DLUTs to convert log mode to REC709 for all major cameras that includes ARRI, RED, SONY, Panasonic, Canon, JVC, BMD, FujiFilm, GoPro and DJI.

FM-21HDR provides 11-17V 4-pin XLR input and 100-240V AC input. A V-mount plate is pre-installed so that the user can attach V-mount battery to power the monitor via D-tap to 4-pin XLR cable.

Key features:

◆ 21.5” 1920×1080 non-glaring LCD
◆ 8-bit LCD, 12-bit internal process
◆ 1000 nits high bright
◆ 3G/HD/SD-SDI, HDMI and CVBS
◆ HDR LUTs: HLG & Dolby vision PQ
◆ Multi-camera logs to Rec.709
◆ DIT user 3DLUT cube upload by USB
◆ Waveform / Vector scope / Histogram
◆ 16-ch embedded audio meters
◆ Peaking focus assist with precision adjustment
◆ Exposure assist / Zebra / Blue only
◆ Anamorphic de-squeeze / Multiple markers
◆ USB firmware upgrade
◆ V-mount or 4-pin XLR or AC input
◆ C-stand mountable (optional)
